Resideo L8148E1265/U Aquastat

Aquastat Relay 180 to 240 Degrees Fahrenheit 15DEG F Fixed Vertical

QUANTITY

Same Day Shipping on orders placed by 4pm EST

Product Overview

The L8148 Aquastat Relays are immersion type hydronic controllers that combine high limit protection with switching relay control of burner and circulator motors.

Immersion type controllers that combine high limit protection with switching relay control of burner and circulator motors

High limit opens burner circuit only

Select models include transformer and accessory terminals for adding a remote low limit controller

TRADELINE models include well adapter tube of heat conductive compounds and range stops

0 to 95% RH non-condensing

Product Details

Brand	Resideo
Product Type	Relay
Temperature	180 to 240DEG F
Differential Temperature	15DEG F Fixed
Mounting	Vertical
Application	Hydronic Heating System Protection
Insulation Depth	1-1/2 to 3IN
Switching Action	SPST High Limit and Circulator
Voltage	120VAC
Controller Type	Immersion
Length	3-1/8IN
Width	4-1/8IN
Height	6-1/8IN

Brand

Resideo

Product Type

Relay

Temperature

180 to 240DEG F

Differential Temperature

15DEG F Fixed

Mounting

Vertical

Application

Hydronic Heating System Protection

Insulation Depth

1-1/2 to 3IN

Switching Action

SPST High Limit and Circulator

Voltage

120VAC

Controller Type

Immersion

Length

3-1/8IN

Width

4-1/8IN

Height

6-1/8IN

Cross Reference

Resideo L8148E1265/U is a suggested replacement option for the identified OEM part numbers below:

OEM MANUFACTURER	OEM PART NUMBER	SUBSTITUTION TYPE^*
HONEYWELL	L8148E1065	UNIVERSAL
HONEYWELL	L8148E1158	UNIVERSAL
HONEYWELL	L8148E1182	UNIVERSAL
HONEYWELL	L8148E1216	UNIVERSAL

* DIRECT refers to a replacement option designed to the OEM specifications for best possible fitment.
* UNIVERSAL replacement options are designed as a functional equivalent and may require adapters, jumpers, switches, etc. (typically provided) in order to function as the original OEM device.

Disclaimer. All recommended replacements in the cross-reference database have been assembled from publicly available resources created by manufactures of HVAC, controls and plumbing products. Stockpile Express assumes no liability in connection with the information contained and makes no guarantees regarding the accuracy of such information. Final selection of a replacement product is the responsibility of the buyer.
