Resideo DP2030C5011/U Contactor

Contactor Definite Purpose 2 Pole 30 Amp 208/240 Volt Multiple Position

QUANTITY

Same Day Shipping on orders placed by 4pm EST

Product Overview

These electromagnetically-operated Definite Purpose Contactors provide switching for starting induction motors.

Meets ARI-780 standard at started ratings (500000 cycle mechanical life, 200000 cycle electrical life and 10000 cycle recycle life), the most demanding ARI requirement

Silver cadmium oxide contacts provide long life under demanding duty cycles

Low profile design allows for more wiring room

Multiple mounting holes and slots for convenient, interchangeable mounting with most competitive devices

30 A at 240/277 VAC AFL, 40 A at 240 to 600 VAC resistive

Product Details

Brand	Resideo
Product Type	Definite Purpose
Number of Poles	2
Amperage	30AMP
Input Voltage/Coil Voltage	208/240V
Mounting	Multiple Position
End Connection	1/4IN Quick Connect
Operating	Electro-Magnetically
Application	Heating, Cooling and Refrigeration
Approvals	ARI-780 Rated, UL Listed, CSA Certified
Length	3-1/3IN
Width	2-1/2IN
Height	2-1/5IN

Brand

Resideo

Product Type

Definite Purpose

Number of Poles

Amperage

30AMP

Input Voltage/Coil Voltage

208/240V

Mounting

Multiple Position

End Connection

1/4IN Quick Connect

Operating

Electro-Magnetically

Application

Heating, Cooling and Refrigeration

Approvals

ARI-780 Rated, UL Listed, CSA Certified

Length

3-1/3IN

Width

2-1/2IN

Height

2-1/5IN

Cross Reference

Resideo DP2030C5011/U is a suggested replacement option for the identified OEM part numbers below:

OEM MANUFACTURER	OEM PART NUMBER	SUBSTITUTION TYPE^*
HONEYWELL	DP2030C5010	UNIVERSAL

* DIRECT refers to a replacement option designed to the OEM specifications for best possible fitment.
* UNIVERSAL replacement options are designed as a functional equivalent and may require adapters, jumpers, switches, etc. (typically provided) in order to function as the original OEM device.
