Resideo V800C1052/U
Gas Valve V800 Standing Pilot Step Opening 0.9 Inch WC-3.5 Inch WC 3/4 x 3/4 Inch NPT 1/2 Pounds per Square Inch 32-175 Degrees Fahrenheit
Sign In for price In Stock
QUANTITY
Same Day Shipping on orders placed by 4pm EST
Product Overview
Used on gas fired standing pilot appliances with 30 mV thermocouple. These gas controls include a manual gas valve, safety shutoff, single millivoltage automatic operator, pressure regulator, pilot gas filter and flow adjustment, pressure tapping, and thermocouple connector.
- Easy to install, adjust and service, all adjustments and connections are accessible from top of control
- Add separate energy cutoff (ECO) where codes call for dual safety shutoff
- Complete safety shutoff on pilot flame failure
- LITE-RITE (OFF-PILOT-ON) lighting sequence
- Single stage application
- 0 to 90 deg in any direction from the upright position of the gas control knob, including vertically mounting
- 60 Hz frequency
- 24 VAC voltage
- Step opening
- Pilot gas outlet: Compression fitting for 1/4 in OD tubing
- Outlet pressure tap: 1/8 in NPT with plug
- Capacity: At 1 in w.c. PD - 335000 Btu/hr, 34000 Btu/hr minimum, 425000 Btu/hr maximum
- Step pressure regulator
- Pressure regulator setpoint: Step setting - 0.9 in w.c. non-adjustable, Full Rate - 3.5 in w.c.
- ECO connector for V800 models part #392451-1
Product Details
| Brand | Resideo |
|---|---|
| Product Type | Standing Pilot Step Opening 0.9IN WC-3.5IN WC |
| Size | 3/4x3/4IN |
| End Connection | NPT |
| Pressure | 1/2PSI |
| Temperature | 32-175DEG F |
| Fuel | Natural Gas |
| Width | 4-1/16IN |
| Height | 4-3/4IN |
| Depth | 3-3/16IN |
Cross Reference
Resideo V800C1052/U is a suggested replacement option for the identified OEM part numbers below:
| OEM MANUFACTURER | OEM PART NUMBER | SUBSTITUTION TYPE* |
|---|---|---|
| HONEYWELL | V800J1005 | DIRECT |
| HONEYWELL | V810C1051 | DIRECT |
| HONEYWELL | V810C1077 | DIRECT |
| HONEYWELL | V8139C1004 | DIRECT |
| HONEYWELL | V8139C1012 | DIRECT |
| HONEYWELL | V8139C1020 | DIRECT |
| HONEYWELL | V8139C1038 | DIRECT |
| HONEYWELL | V8139C1053 | DIRECT |
| HONEYWELL | V8139C1079 | DIRECT |
| HONEYWELL | V8235G1008 | DIRECT |
| HONEYWELL | V8235G1016 | DIRECT |
| HONEYWELL | V8235G1024 | DIRECT |
| WHITE RODGERS | 36C12-310 | DIRECT |
* DIRECT refers to a replacement option designed to the OEM specifications for best possible fitment.
* UNIVERSAL replacement options are designed as a functional equivalent and may require adapters, jumpers, switches, etc. (typically provided) in order to function as the original OEM device.
Disclaimer. All recommended replacements in the cross-reference database have been assembled from publicly available resources created by manufactures of HVAC, controls and plumbing products. Stockpile Express assumes no liability in connection with the information contained and makes no guarantees regarding the accuracy of such information. Final selection of a replacement product is the responsibility of the buyer.
